Model | RT-640 | Printing Technology | Piezoelectric inkjet | Media | Width | 259 to 1625 mm (10.2 to 64 in.) | Thickness | Max. 1 mm (39 mil) | Roll outer diameter | Max. 210 mm (8.3 in.) | Roll weight | Max. 40 kg (88 lb) | Core diameter*1 | 76.2 mm (3 in.) or 50.8 mm (2 in.) | Printing width*2 | Max. 1615 mm (63.6 in.) | Ink | Type | Texart ink, 1000 cc pouch | Colours | 4 colours (Cyan, Magenta, Yellow, Black) 8 colours (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Orange, Violet) 8 colours (Cyan, Magenta, Yellow, Black, Fluorescent Pink, Fluorescent Yellow, Orange, Violet) (Choose from CMYK+LcLmOrVi and CMYK+OrViFpFy options) | Print resolution (dots per inch) | Max. 1440 dpi | Distance accuracy*3 | Error of less than ±0.3% of distance travelled, or ±0.3 mm, whichever is greater | Connectivity | Ethernet (10BASE-T/100BASE-TX, automatic switching) | Power-saving function | Automatic sleep feature | Power requirements | AC 100 to 240 V ±10%, 1.5 A, 50/60 Hz | Power consumption | During operation | Approx. 140 W | Sleep mode | Approx. 31 W | Acoustic noise level | During operation | 62 dB (A) or less | During standby | 49 dB (A) or less | Dimensions (with stand) | 2650 (W) x 795 (D) x 1600 (H) mm (104.4 x 31.3 x 63 in.) | Weight (with stand) | 160 kg (353 lb) | Environment | Power on | Temperature: 18 to 25°C (64.4 to 77°F), humidity: 35 to 65% RH (no condensation) | Power off | Temperature: 15 to 30°C (59 to 86°F), humidity: 20 to 80% RH (no condensation) | Included items | RIP software, take-up system, exclusive stands, power cable, media clamps, media holder, replacement blades for separating knife, User's Manual, etc. | Software | For 4 colour ink configuration a choice of either VersaWorks Dual or ErgoSoft Roland Edition 2 For 8 colour ink configuration ErgoSoft Roland Edition 2 |
Print Modes | Resolution | Pass | Speed | 4 Colour CMYK | | | | High Speed | 540 x 360 | 2 | 32.6 sqm/hr | Production | 540 x 360 | 3 | 22 sqm/hr | Standard | 360 x 720 | 4 | 16 sqm/hr | High Quality | 720 x 720 | 8 | 8 sqm/hr | 8 Colour CMYKLcLmLyOrViFpFy | | | | High Speed | 540 x 360 | 4 | 16 sqm/hr | Production | 540 x 360 | 6 | 10.7 sqm/hr | Standard | 360 x 720 | 8 | 8 sqm/hr | High Quality | 720 x 720 | 12 | 5.4 sqm/hr |
*1 The media holder for this machine is exclusively designed for media rolls with a paper tube measuring 76.2 mm (3 in.) in diameter. To use 50.8 mm (2in.) media rolls, the optional media flanges are required. *2 The length of the production run is subject to the limitations of the program. *3 Media type: Media specified by Roland DG Corporation. Temperature: 25°C (77°F), humidity: 50%. Roll media must be loaded correctly. Excluding expansion / contraction of the media. All corrections or adjustment functions of this machine have been made properly. Print travel: 1 m. Specifications, designs and dimensions listed may be subject to change without notice. ErgoSoft Roland Edition 2 System Requirements | Operating system | Windows® 10 (32/64-bit) Windows® 8/8.1 (32/64-bit) Windows® 7 Professional (32/64-bit) Windows® 7 Home (32/64-bit) | CPU | Intel® Core™ i3; 3 GHz or faster recommended | RAM | 8GB or more recommended | Video card and monitor | Screen resolution of 1600 x 900 or higher recommended | Free disk space (HDD/SSD) | 100 GB or more recommended |
Roland VersaWorks Dual System Requirements | Operating system | Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate/Professional (32/64 bit) | Hard-disk file system | NTFS format | CPU | Intel® Core™2 Duo, 2.0 GHz or faster recommended | RAM | 2 GB or more recommended | Video card and monitor | A resolution of 1280 x 1024 or more recommended | Free hard-disk space | 40 GB or more recommended | Ethernet Connection | 100 mbps | Other | Internet connection recommended |
Roland VersaWorks Dual is a 32-bit application and therefore runs in WOW64 (Windows-on-Windows 64) when running on 64-bit versions of Windows operating systems. |
