Texart RT-640M

Leverantörer Roland   Eco-SolventUVLEDResinSublimeringDTF - Direkt-till-filmCutters
[Translate to Sverige:] Roland Texart RT-640M, Marabu Scandinavia

Översikt

[Translate to Sverige:] Roland Texart RT-640M, Marabu, textiltryck

De unika utskriftsmöjligheterna i Texart RT-640M innebär att du kan tryck direkt på polyesterbaserade eller behandlade applikationer såväl som transferpapper med samma bläck och rip. Det finns helt enkelt ingen annan enhet i sin klass som kan göra allt detta på en enhet. Med hjälp av Texart Sublimation-bläck, och den branschledande ErgoSoft Roland Edition 2 RIP-programvaran (som ingår i paketet), kan du helt enkelt lägga till ett efterbehandlingssystem (t.ex. värmepress, kalender, 3D-vakuum eller ugn ).

Broschyr

Marabu är en certifierad partner till Roland DG och säljer Texart RT-640M . Teckna ett serviceavtal i samband med ditt köp för att säkerställa att din maskin presterar som bäst alltid.

Serviceavtal

Funktioner

[Translate to Sverige:] Roland DG, Texart RT-640, Marabu, textiltryck
  • Utrustad med ett justerbart frontrullsystem, för att säkerställa stabil och oavbruten produktion
  • Roland Texart SBL3-bläck med snabba torkningstider och överföringshastigheter.
  • Rip ErgoSoft Roland Edition 3
  • Backup bläckpåse när den första påsen tar slut
  • Optimerade skrivarhuvuden

Broschyr

Applikationer

[Translate to Sverige:] Roland Texart RT-640M, Textil, Marabu
  • Soft Signage
  • Dubbelsidiga flaggor
  • Sportkläder
  • Inredning
  • Mode
  • Rigida skivor

Specifikationer

ModelRT-640M
Printing TechnologyPiezoelectric inkjet
Media
Width259 to 1625 mm (10.2 to 64 in.)
ThicknessMax. 1 mm (39 mil)
Roll outer diameterMax. 210 mm (8.3 in.)
Roll weightMax. 40 kg (88 lb)
Core diameter*176.2 mm (3 in.) or 50.8 mm (2 in.)
Printing width*2Max. 1615 mm (63.6 in.)
InkTypeTexart ink, 1000 cc pouch
Colours4 colours (Cyan, Magenta, Yellow, Black)
8 colours (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Orange, Violet)
8 colours (Cyan, Magenta, Yellow, Black, Fluorescent Pink, Fluorescent Yellow, Orange, Violet) (Choose from CMYK+LcLmOrVi and CMYK+OrViFpFy options)
Print resolution (dots per inch)Max. 1440 dpi
Distance accuracy*3 Error of less than ±0.3% of distance travelled, or ±0.3 mm, whichever is greater
ConnectivityEthernet (10BASE-T/100BASE-TX, automatic switching)
Power-saving functionAutomatic sleep feature
Power requirementsAC 100 to 240 V ±10%, 1.5 A, 50/60 Hz
Power consumptionDuring operationApprox. 140 W
Sleep modeApprox. 31 W
Acoustic noise levelDuring operation62 dB (A) or less
During standby49 dB (A) or less
Dimensions (with stand)2650 (W) x 795 (D) x 1600 (H) mm (104.4 x 31.3 x 63 in.)
Weight (with stand)160 kg (353 lb)
EnvironmentPower onTemperature: 18 to 25°C (64.4 to 77°F), humidity: 35 to 65% RH (no condensation)
Power offTemperature: 15 to 30°C (59 to 86°F), humidity: 20 to 80% RH (no condensation)
Included itemsRIP software, take-up system, exclusive stands, power cable, media clamps, media holder, User's Manual, etc.
Software For 4 colour ink configuration a choice of either VersaWorks 6 or ErgoSoft Roland Edition 3
For 8 colour ink configuration ErgoSoft Roland Edition 3
Print ModesResolutionPassSpeed
4 Colour CMYK
High Speed540 x 360232.6 sqm/hr
Production540 x 360322 sqm/hr
Standard360 x 720416 sqm/hr
High Quality720 x 72088 sqm/hr
8 Colour CMYKLcLmLyOrViFpFy
High Speed 540 x 360416 sqm/hr
Production 540 x 360610.7 sqm/hr
Standard360 x 72088 sqm/hr
High Quality720 x 720125.4 sqm/hr

*1 The media holder for this machine is exclusively designed for media rolls with a paper tube measuring 76.2 mm (3 in.) in diameter. To use 50.8 mm (2in.) media rolls, the optional media flanges are required.

*2 The length of the production run is subject to the limitations of the program.

*3 Media type: Media specified by Roland DG Corporation. Temperature: 25°C (77°F), humidity: 50%. Roll media must be loaded correctly. Excluding expansion / contraction of the media. All corrections or adjustment functions of this machine have been made properly. Print travel: 1 m.

Specifications, designs and dimensions listed may be subject to change without notice.

ErgoSoft Roland Edition 3 System Requirements
Operating systemWindows® 10 (32/64-bit)
CPUIntel Core i7-7700K (4.2 GHz) Socket 1151 or faster
RAM8GB or more recommended on 32-Bit - 16GB or more recommended on 64-Bit
Video card and monitorDisplay resolution of 1600 x 900 or higher recommended
Free disk space (HDD/SSD) 2 Solid State Disks (SSD) recommended.
512 GB to run the program installation
512 GB to store ripped data and spooling data
VersaWorks 6 System Requirements
Operating system Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate/Professional (32/64 bit)
CPUIntel® Core™2 Duo, 2.0 GHz or faster recommended
RAM2 GB or more recommended
Video card and monitorA resolution of 1280 x 1024 or more recommended
Free hard-disk space40 GB or more recommended
OtherInternet connection recommended

VersaWorks 6 is 64-bit native application.A 32-bit binary RIP will be installed automatically if the installer detects a 32-bit OS.

Bläck & tillval

Roland bläck

SBL3-CY, Dye Sublimation Texart ink Cyan, 1000 cc
SBL3-MG, Dye Sublimation Texart ink Magenta, 1000 cc
SBL3-YE, Dye Sublimation Texart ink Yellow, 1000 cc
SBL3-BK, Dye Sublimation Texart ink Black, 1000 cc
SBL3-LC, Dye Sublimation Texart ink Light cyan, 1000 cc
SBL3-LM, Dye Sublimation Texart ink Light magenta, 1000 cc
SBL3-OR, Dye Sublimation Texart ink Orange, 1000 cc
SBL3-VI, Dye Sublimation Texart ink Violet, 1000 cc
SBL3-FP, Dye Sublimation Texart ink Fluor pink, 1000 cc
SBL3-FY, Dye Sublimation Texart ink Fluor yellow, 1000 cc

Tillval

TU3-64, Take Up Unit
