Förskjutna skrivhuvuden, ECO-UV-bläck och True Rich Color i kombination med användarvänliga funktioner gör TrueVIS LG-300 till den ultimata storformatsskrivaren inom professionell UV Print&Cut. Chassiet har fått en ny design med kvalitativa komponenter. Fler kompatibla material med förbättrad hantering vilket gör att LG är perfekt för obevakade utskrifter.
Marabu är en certifierad partner till Roland DG och säljer TrueVIS LG, storformatsskrivare. Teckna ett serviceavtal i samband med ditt köp för att säkerställa att din maskin presterar som bäst alltid.
Model | LG-640 | LG-540 | LG-300 | ||||
Printing method | Piezo ink-jet method | ||||||
Media | Width | 335 to 1625 mm (13.2 to 64 in.) | 295 to 1371 mm (11.7 to 54 in.) | 182 to 762 mm (7.2 to 30 in.) | |||
Thickness | Max. 1.0 mm (39.3 mil) with liner, for printing Max. 0.4 mm (15.7 mil) with liner and 0.22 mm (8.6 mil) without liner, for cutting | ||||||
Roll outer diameter | Max. 250 mm (9.8 in.) | ||||||
Roll weight | Max. 45 kg (99 lb.) | Max. 35 kg (77 lb.) | Max. 30 kg (66 lb.) | ||||
Core diameter | 76.2 mm (3 in.) or 50.8 mm (2 in.) | ||||||
Printing / cutting width 1 | Max. 1600 mm (62.9 in.) | Max. 1346 mm (52.9 in.) | Max. 736 mm (28.9 in.) | ||||
Ink | Type | ECO-UV (EUV5P) 750ml pouch | |||||
Colours | Eight Colours (Cyan, Magenta, Yellow, Black, Gloss, Primer, White, and Red) Eight colours (Cyan, Magenta, Yellow, Black, Primer White, Orange, and Red) Eight colours (Cyan, Magenta, Yellow, Black, Gloss, White, Orange, and Red) Seven colours (Cyan, Magenta, Yellow, Black, White, Orange, and Red) Seven colours (Cyan, Magenta, Yellow, Black, Gloss, Primer, and White) Six colours (Cyan, Magenta, Yellow, Black, Gloss, and White) Four colours (Cyan, Magenta, Yellow, and Black) | ||||||
Ink curing unit | Built-in UV-LED lamp | ||||||
Print resolution (dots per inch) | Max. 1200 dpi | ||||||
Cutting speed | 10 to 300 mm/s (0.39 to 11.8 in./s) | ||||||
Blade force 2 | 30 to 500 gf | ||||||
Blade | Type | Roland CAMM-1 series blade | |||||
Offset | 0 to 1.500 mm (0 to 59 mil) | ||||||
Software resolution (when cutting) | 0.025 mm/step (0.98 mil/step) | ||||||
Media heating system 3 | Front heater set temperature: 30 to 55 ℃ (86 to 131 °F) | ||||||
Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | ||||||
Power-saving function | Automatic sleep feature | ||||||
Power requirements | 100-120/220-240 Va.c. 50/60 Hz 6.5/3.2 A | 100-120/220-240 Va.c. 50/60 Hz 6.5/3.2 A | 100-120/220-240 Va.c. 50/60 Hz 5.7/2.6 A | ||||
Power consumption | During operation | Approx. 800 W | Approx. 800 W | Approx. 650 W | |||
Sleep mode | Approx. 85 W | ||||||
Acoustic noise level | During operation | 63 dB (A) or less | |||||
During standby | 58 dB (A) or less | ||||||
Dimensions (with stand) | 2902 mm x 748 mm x 1412 mm (114.3 in. x 29.5 in. x 55.6 in.) | 2648 mm x 748 mm x 1412 mm (104.3 in. x 29.5 in. x 55.6 in.) | 2038 mm x 748 mm x 1412 mm (80.3 in. x 29.5 in. x 55.6 in.) | ||||
Weight (with stand) | 209 kg (461 lb.) | 179 kg (395 lb.) | 168 kg (371 lb.) | ||||
Environment | During operation 4 | Temperature : 20 to 32 ℃ (68 to 89.6 °F), Humidity: 35 to 80 % RH (no condensation) | |||||
Not operating | Temperature : 5 to 40 ℃ (41 to 104 °F), Humidity: 20 to 80 % RH (no condensation) |
Specifications, designs and dimensions listed may be subject to change without notice
1The length of printing or cutting is subject to the limitations of the program.
2500 gf is the maximum instantaneous blade force. The blade force must be adjusted according to details such as the media thickness.
3Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment.
Depending on the ambient temperature and media width, the preset temperature may fail to be reached.
4Operating environment (Use in an operating environment within this range.)
